Monacor DADC-144DT Dante® 4 input, 4 output transceiver
Monacor DADC-144DT Dante® 4 input, 4 output transceiver
Monacor DADC-144DT Dante® 4 input, 4 output transceiver

Monacor DADC-144DT Dante® Transceiver

SKU: DADC-144DT

£429.49 + VAT    £515.39 incl. VAT

Dante® 4 input, 4 output transceiver

Out of stock

Ethernet
LAN

PDF

Description

Monacor DADC-144DT Dante® 4 input, 4 output transceiver

  • 4 analogue XLR audio inputs
  • 4 analogue XLR audio outputs
  • 4-channel Dante® input/output (EtherCon/RJ45)
  • Analogue input and output levels can be adjusted individually via recessed potentiometers
  • 48 V phantom power can be activated as required for each analogue input
  • Mute function for each analogue output
  • Dante® sources and Dante® receiver can be combined via software
  • Encoding/decoding: 16/24/32 bits
  • Sampling rates: 44.1/48/88.2/96 kHz
  • Frequency range: 20-20,000 Hz
  • LED display for indicating signal, peak, network link, network act and power
  • Metal housing
  • 482 mm (19″) rack installation, 1 RU
  • Description: 4-channel Dante® transceiver
  • Frequency range: 20-20,000 Hz
  • Input signal: 2.3 V max.
  • Input sensitivity: 5.7 mV-2.3 V
  • Gain: 0.2-5.2x
  • Phantom power: 48 V
  • S/N ratio: > 90 dB
  • THD: < 0.005%
  • Admissible ambient temperature: 0-40 °C
  • Power supply: 230 V/50 Hz/15 VA
  • Dimensions: 482 x 44.5 x 238 mm, 1 RU
  • Weight: 2.9 kg
  • Inputs: 4 x XLR, bal.
  • Outputs: 4 x XLR, bal.
  • Other features: 1 x EtherCon/RJ45
System requirements Dante®: Windows 7/8/10 or MacOS
The brand Dante® as well as any Dante® software which may have been integrated into these products are licensed by Audinate Pty Ltd.
RJ45 connection is only possible with short body plug. Standard RJ45 plugs are not suitable.

System requirements Dante®: Windows* 7/8.1/10 or MacOS 10.9.5/10.10.5/10.11

Click here for Audinate Dante® online training and certification

Please note:
32-bit applications, including the current version of the DSP controller, are no longer supported under the MacOS version 10.15 (Catalina). The controller software is currently being updated for 64-bit MacOS Catalina. Users of older MacOS versions as well as Windows users are not affected by this change.
Apple’s announcement will give you further information on the change to 64-bit technology
See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

Additional information

Weight2.9 kg
Dimensions23.8 × 48.2 × 4.45 cm
Connection

3 Pin XLR (Female), 3 Pin XLR (Male), RJ45 (CAT5e, CAT6, CAT7)

Colour

Black

Condition

New

Brand

Monacor

Monacor is one of Europe’s largest distributors of PA sound and lighting equipment. Monacor understand public address and sound reinforcement comprehensively and offer a diverse range of products for all commercial sound and lighting needs. In addition to classic sound systems for sound reinforcement such as music systems, amplifiers, loudspeakers, and mixing desks, the full portfolio also includes complex conference systems, accessories for voice alarm or mobile amplifier systems, as well as induction loop sound systems, 100v line PA and megaphones. Whether you want to bring sound to one person or thousands: Monacor has the right solution for you. Our professional and commercial sound products, wireless microphones and induction loops are carefully chosen for sale on our website by Sound Services – not everything from every manufacturer is there. Based on feedback, customer reviews and our own observations we list items that are popular, reliable and good value for money. If there are products not shown on our website that you feel we may be able to quote for, please just ask!

User Manuals

Software & Downloads

App for Windows OS

App for Mac OS

Dante Controller

Dante Virtual Soundcard
