Eagle F-4 Mixer Amplifier with Monacor DN-8090 Fist Microphone

Description

Eagle F-4 mixer amplifier with Monacor DN-8090 fist microphone

Bundle includes:

• Eagle F-4 12w RMS public address mixer amplifier
• Monacor DN-8090 hand-held dynamic PTT microphone

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.

F-4

Eagle F-4 12w RMS public address mixer amplifier will run from a 12v car battery and can be connected to low impedance loudspeakers that are rated between 4 and 8 ohms total load

The P101 provides low-cost amplification with a microphone input with level control, auxiliary input with level control and Fog/Siren output. The power output of 12 Watts can be fed into a combined speaker load of between 4 and 16 Ohms and the unit is supplied with mounting hardware.

• Auxillary Input: 85 mV/10 k Ohm
• Colour: Black
• DC Input: 12v
• Frequency Response: 80-15000 Hz
• Microphone Input: 3.5 mV 200-50 k Ohm
• Power: 12w RMS
• Priority Microphone: No
• Product Dimensions: 40 x 150 x 150 mm
• Net weight: 0.79 kg

Monacor DN-8090 / DH-95NP hand-held dynamic PTT microphone

• Low impedance
• With push-to-talk button
• Particularly suitable for PA
• Supplied with microphone holder
• 300-6,000 Hz, 2.5 mV/Pa/1 kHz, 500 Ω
• Audio frequency range: 300-6,000 Hz
• Nominal impedance: 500 Ω
• Sensitivity: 2.5 mV/Pa
• Admiss. ambient temp: 0-40 °C
• Weight: 165 g
• Cable: helix connection cable
• Connection: 6.3 mm stereo plug
