Description
IND-240 240w 100v line indoor public address sound, paging and background music systems are for supermarkets, mini marts or stores, workshops, schools and offices. Systems are available with various speaker combinations and output wattages for different venue sizes and environments
Available with up to 14 x black or white wall cabinet speakers
Please email if you require a different combination of speakers
This package must be wired as a 100v line sound system – please see user manuals tab
Mixer amplifier:
- 240w RMS
- Power supply: 170-264Vac, 50Hz (IEC)
- DC power: 24Vdc (screw terminals)
- Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line
- Input sensitivity : mic 1 (balanced): -53dBV
- Input impedance : mic 1: 5k Ohms
- Input sensitivity : line (unbalanced): -15dBV (-18.5dBV line 5)
- Input impedance : inputs 2-5: 1k Ohms
- Line output: RCA
- Speaker outputs: 4 switched + 1 non-switched 100V / 4-16 Ohms / COM
- Controls: Mic1, mic/line2+3, line4+5, bass, treble, master volume
- Equaliser : bass: 100Hz ±10dB
- Equaliser : treble: 10kHz ±10dB
- Rear panel switches: Phantom, Vox, Mic/Line (2 + 3)
- Phantom power: +20V (mic 1 XLR, switchable)
- Audio source: DAB+/FM tuner, USB/SD player, Bluetooth receiver
- Emergency control: 24V contacts – mute all except Mic.1 when triggered
- Bluetooth version: 5.0
- THD: <1.0%
- Output power : rms: 240W
- Fuse: T5A
- Dimensions: 433 x 320 x 88mm
- Weight: 7.37kg
- Use terminal block to extend speaker cable
- Do not short speaker cables together
Cabinet speakers:
- Packed in pairs – ie: order 2 and receive 4 (2 pairs)
- 100V line operation with various power taps
- 2-way version
- Dome tweeter
- Excellent sound quality
- Power selector switch
- Movable mounting bracket supplied
- Corner mounting possible
- Black or white
Desk Paging Microphone:
- Dynamic, cardioid characteristic
- Close-talk type
- Low-noise push-to-talk switch, latching or non-latching operation
System Includes:
- 1 x 240w mixer amplifier with Bluetooth and media player
- Up to 8 x black or white wall cabinet speakers (please note that speakers are packed and supplied in pairs) – see options
- 1 x Desk paging microphone
- 2 x Input connector leads for MP3 players etc.
- 100m speaker cable – see options
Sound Services deliver this complete sound system without extra charge to most mainland UK addresses
Speaker cable assembly and installation of these systems require some DIY assembly skills – you should only require basic DIY tools together with speaker, amplifier and cable fixings etc.
Constant development means that illustrations are only representative and items supplied may be newer or improved models that are available at the time of your order
See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version
