Mercury IPS1000-12 Inverter

Description

Mercury IPS1000-12 1,000w 12v power inverter

Soft start pure sine wave power inverter. These high efficiency Mercury IPS-12 power inverters use a pure sine wave to power 230V mains equipment from a 12V battery or DC power supply. Perfect for use while camping, in commercial vans/lorries, or as a means to convert charged batteries for back-up power in case of a blackout. Ideal for use with TVs, computers and other everyday appliances.

• Over 90% efficiency
• Soft start minimises inverter shutdown when using large inductive loads
• High accuracy output wave form with less than 4% THD
• Reverse polarity protection
• Lowithoutver voltage input protection
• Short circuit, overload and overheat protection
• LED and audible fault indicator
• Supplied with 1 pair of 800mm DC power cables and a spare blade fuse
• Please note: Ensure the device is well within the inverter output power rating. We recommend using an inverter capable of supplying a minimum of 3 times the device’s rated power to avoid damage to the inverter by any current surge (especially for fridges and freezers which can surge up to 7 times the rated power)
• Built in 1000mA USB socket
• Continuous power: 1000W
• Voltage: 12V
• Input voltage: 10.8 – 15.5Vdc
• Standby no load current: 0.8A
• Cable type: Ring terminal
• Cable terminals: 8.5/16.5mm Ring
• Inverter terminals: M8 screws
• USB output current: 1A
• Dimensions: 365 x 150 x 70mm
• Weight: 2.74kg

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
