Description
Clever Acoustics MA 2120 120w 5 input 100v line mains & 24v DC mixer amplifier
The MA series amplifiers are ideal for installation into shops, offices and commercial premises. Featuring three microphone inputs, two AUX inputs and one telephone input. MIC 1 features switchable +48V phantom power and adjustable VOX priority over the other inputs. Individual gain controls for microphone and AUX inputs plus controls for bass, treble and master volume.
- 19″ rack mountable chassis (removable rack ears)
- Three microphone inputs
- Two AUX inputs
- MIC 1 features VOX priority and VOX level on rear panel
- MIC 1, 2 and 3, AUX 1, 2 and master volume and bass/treble tone controls
- Switchable +48V phantom power on MIC 1
- Line output via phono sockets
- Short circuit, overload and high temperature protection
- Built-in priority functions for telephone override for AUX and MIC 1, 2 and 3
- Optional DC input for use with battery backup power sources or for operation using high capacity batteries
- LED VU meter with temperature and protect indication
- Speaker output: 70V, 100V or 4-16Ω
- Frequency response: 50Hz-18kHz
- Power supply: 240v AC 50Hz / 24v DC
- Dimensions (H x W x D): 88 x 484 x 303mm
- Weight: 7.8kg
See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
