Monacor PA-924 Mixer Amplifier

Monacor PA-924 240w mono PA mixing amplifier

• 240 W
• Fan cooled
• 4 balanced microphone inputs with selectable priority
• 4 line inputs
• Speaker outputs via screw terminals
• Balanced line output
• Record output
• Insert facility, e.g. for effect units, equalizers, feedback controllers
• 2-tone or 4-tone chime, can be activated externally
• Input level control and output level control
• 2-way tone control for the output
• Switchable 48 V phantom power for microphone inputs
• Temperature-controlled fan
• Mains operation or 24 V emergency power operation
• Removable mounting brackets
• Input channels: 5
• Power rating: 240 W
• Peak music power output (PMAX): 340 W
• Inputs: 2.5-100 mV (mic), 350 mV (line)
• Frequency range: 50-16,000 Hz, ± 3 dB
• Equalizer bass: ± 10 dB/100 Hz
• Equalizer treble: ± 10 dB/10 kHz
• S/N ratio: > 75 dB
• THD: < 0.1%
• Power supply: 230v AC – 640 VA and 24v DC – 18 A
• Admiss. ambient temp: 0-40 °C
• Dimensions: 482 x 95 x 390 mm, 2 RS
• Rack spaces: RS 2
• Weight: 13 kg
• Connections: 4 x XLR (mic), 4 x RCA L/R (line), 1 x XLR (line out), 1 x RCA L/R (line out), screw terminals (speakers)

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
