Fonestar POWERBASS-8T Series Bass Speakers

Description

Fonestar POWERBASS-8T series 120W RMS bass speakers

Subwoofer with excellent bass response, ideal for sound reinforcement in background music. Enhances the bass content of music, delivering deep and powerful bass without distortion. Unique FONESTAR design with stylish shapes and compact size. Available in white or black. Can be installed on the floor or wall and blends seamlessly into any space. Fully protected loudspeaker. Various options for transformer power selection and low impedance connection to adapt to any installation. Incorporates a low-pass filter to adjust its frequency response according to the music type and room characteristics. Bass-reflex reinforcement, utilizing rear speaker radiation to enhance bass. Perfect for ambient music applications in retail, bars, cafes, etc.

• Available in black or white finish
• Power (RMS): 120 W RMS (IEC 60258-5 Average rated power, 100 hours)
• Loudspeakers: 1 x 8″ woofer
• Frequency Response:
  • 47-300 Hz (-10 dB) @ FPB 150 Hz
  • 47-400 Hz (-10 dB) @ FPB 400 Hz
  • 47-650 Hz (-10 dB) @ Bypass
• Impedance:
  • 120W RMS @ 100V (83Ω)
  • 85W RMS @ 70V (57Ω)
  • 60W RMS @ 100V/70V (166Ω/83Ω)
  • 30W RMS @ 100V/70V (333Ω/166Ω)
  • 15W RMS @ 100V/70V (666Ω/333Ω)
  • 7.5 W RMS @ 70 V (666 Ω)
  • Low Z: 6Ω
• Sensitivity: 85dB @ 1W/1m
• Sound Pressure: 103 dB @ rated power/1m
• Switch: W selector in high Z and low Z
• Low pass filter selector: 150 Hz / 400 Hz / Bypass
• Material: MDF
• Connector: Euroblock input and output
• Temperature Range:
  • Operation: -10º ~ 50ºC
  • Storage: -20º ~ 50ºC
• Colour Options:
  • Black
  • White (RAL 9003)
• Dimensions: 545 x 150 x 337 mm depth
• Weight: 9.4kg
• Accessories:
  • Wall mounting brackets
  • Screws and mounting accessories
• Optional: Ceiling mount POWERBASS-CMB

See the ‘User Manuals’ tab on the left of this page – as manufacturers are making instruction sheets and user manuals available for download only and your purchase may not include a printed version.
